Mild Steel Low Alloy High Penetration Excellent Arc Stability Polarity Dcep/Ac/Dc+/Elongation 25%
(Pack of 15)

SKU:EG10740000 Item#: EG10740000

Lawson Products

Deep-Arc is designed perfectly for the maintenance welder. It welds through dirt, grease and other contaminants. It works at low amperage for use on low, open circuit buzz boxes. Its ability to penetrate makes it an ideal choice for poor fit-ups and root passes on thick steel.
• Welds through contaminants - little or no pre-cleaning required; including pass-over-pass without chipping slag
• Wide Amperage Range - Allows welder to control penetration
• Superior Penetration - Excellent for root and cover passes on pipe assembly or repairs
• Low Amperage - Prevents burn through on thin gauge steel and enables use on low voltage buzz boxes
• Excellent Arc Stability - Works well on inverter-type arc welders and AC machines
• Tensile strength: up to 85,000 psi/586 Mpa
• Yield strength: up to 69,000 psi/476 Mpa
• Elongation: 25%
• Machinability: Excellent
• Current: DCEP (DC+) or AC

Check Availability

Quantity

Frequently Bought Together

106 Mild Steel All Purpose Electrode 1/16

Item#: EG1067000G

664 Self Shielding Mild Steel Flux Core Mig Wire .035X10LB

Item#: EG66440035

660 Mild Steel Flux Core Low Hydrogen Mig Wire 1/16X33Lb

Item#: EG66080062

Hex Nut Grade 8 Alloy Steel 5/16-18

SAE Flat Washer Thru-Hardened Steel 3/8"

Qwik Stik® Electrolyte Powder Mix Grape

556 Aluminum TIG Wire 1/16"

707 Dissimilar Steel Stick Rod Electrode 3/32"

E7018 Mild/Carbon Steel Stick Electrode 1/8

Item#: EG12047019

701 Mild/Carbon Steel Stick Rod Electrode 3/16"

3880 Stainless Steel Stick Rod Electrode 1/8"

701 Mild/Carbon Steel Stick Rod Electrode 3/32"

Product Description

Deep-Arc is designed perfectly for the maintenance welder. It welds through dirt, grease and other contaminants. It works at low amperage for use on low, open circuit buzz boxes. Its ability to penetrate makes it an ideal choice for poor fit-ups and root passes on thick steel.
• Welds through contaminants - little or no pre-cleaning required; including pass-over-pass without chipping slag
• Wide Amperage Range - Allows welder to control penetration
• Superior Penetration - Excellent for root and cover passes on pipe assembly or repairs
• Low Amperage - Prevents burn through on thin gauge steel and enables use on low voltage buzz boxes
• Excellent Arc Stability - Works well on inverter-type arc welders and AC machines
• Tensile strength: up to 85,000 psi/586 Mpa
• Yield strength: up to 69,000 psi/476 Mpa
• Elongation: 25%
• Machinability: Excellent
• Current: DCEP (DC+) or AC

Technical Specifications

Item#:	EG10740000
Welding Process	Stick
Type	Stick
Diameter	1/8 "
Tensile Strength	85,000 PSI
Elongation	25 %
Base Metal	Mild And Medium Carbon Steel
Polarity	DCRP
UNSPSC #:	23271810
TAA Compliant:	Yes
Weight:	15.31 lb
