Home Facility + Site Compression Spring 11/16 x 2-3/4"
Facility + Site

Compression Spring 11/16 x 2-3/4"
(Pack of 2.0)

Lawson Products

• The most common spring type
• Used in applications where mechanical parts must be separated by constant applied force
To determine the spring rate for a length not shown, divide the original length by the desired length, then multiply by the original spring rate.Example: The rate for No. 89581, cut to 1", would be 3 divided by 1, then multiplied by 2.0, or 6 lbs. per inch.

Read More
Check Availability

California Proposition 65: Not Applicable
www.P65Warnings.ca.gov

Catalog page#: 16-36, 16-39

Frequently Bought Together


Valve Action® Permanent Paint Marker Blue

Item#: CW4892

WypAll X60 Teri Wiper 12.5 x 13.4"

Item#: 29374

Reclaimed Mixed Color T-Shirt Rags

Item#: 1648131

WypAll X80 ShopPro Towel 12.5 x 13.4"

Item#: 29372

TigerGrip 8 Mil Nitrile Glove Orange 2X-Large

Item#: 1677892

Oil-Only Sorbent Pad

Item#: SF11603

Locknut with Nylon Insert Grade 8 5/16-18

Item#: 53980

Lock Washer Alloy Steel 3/8"

Item#: A530

SAE J995C Locknut with Nylon Insert Grade 8 1/2-13

Item#: 53983

Push Broom Fine Sweeping 36"

Item#: 95382

Replacement Broom Handle with Threaded Metal End

Item#: 92047

Multi-Flow Truck Wash Brush 10 x 3"

Item#: 96891

Compression Spring Kit 166Pcs

Item#: LP626

Compression Spring 1/4 x 1-3/8"

Item#: 89624

Compression Spring 3/32 x 1-3/8"

Item#: 89635

Product Description

• The most common spring type
• Used in applications where mechanical parts must be separated by constant applied force
To determine the spring rate for a length not shown, divide the original length by the desired length, then multiply by the original spring rate.Example: The rate for No. 89581, cut to 1", would be 3 divided by 1, then multiplied by 2.0, or 6 lbs. per inch.

Technical Specifications

Item#: 89608
Type Compression Spring
O.D. 29/32 "
Length 2-3/4 "
I.D. 11/16 "
Wire Diameter 0.105 "
Wire Gauge 12
Number of Coils 11
Rate 37.5 lb./in.
Maximum Work Load 50 lb
Material Steel
UNSPSC #: 31161904
TAA Compliant: Yes
Weight: 0.13 lb
