Compression Spring 5/16 x 1-1/2"
(Pack of
10.0)
• The most common spring type
• Used in applications where mechanical parts must be separated by constant applied force
To determine the spring rate for a length not shown, divide the original length by the desired length, then multiply by the original spring rate.Example: The rate for No. 89581, cut to 1", would be 3 divided by 1, then multiplied by 2.0, or 6 lbs. per inch.
Couldn't load pickup availability
California Proposition 65: Not Applicable
www.P65Warnings.ca.gov
Frequently Bought Together
Automotive Refinishing Tape 3/4" x 60 Yards
Couldn't load pickup availability
Round Tag Brass 1-3/8"
Couldn't load pickup availability
Blue GT Series Extra Heavy Duty Wiper Roll
Couldn't load pickup availability
Automotive Refinishing Tape 2" x 60 Yards
Couldn't load pickup availability
500G Tsunami Grip® Light Coated Gloves
Couldn't load pickup availability
Sqweeze® ZERO – Sugar Free Hydration Freeze Pops
Couldn't load pickup availability
Hex Nut Grade 8 Alloy Steel 1/2-13
Couldn't load pickup availability
SAE Flat Washer Thru-Hardened Steel 5/16"
Couldn't load pickup availability
USS Flat Washer Thru-Hardened Steel 5/16"
Couldn't load pickup availability
Rectangular Tag Brass 2 x 1"
Couldn't load pickup availability
Trash Can Liner Super Strong 39 x 56"
Couldn't load pickup availability
GT Series White Grab and Go Wiper Roll
Couldn't load pickup availability
Compression Spring 9/32 x 2"
Couldn't load pickup availability
Compression Spring 13/32 x 2-3/8"
Couldn't load pickup availability
Compression Spring 3/16 x 1-1/4"
Couldn't load pickup availability
Product Description
• The most common spring type• Used in applications where mechanical parts must be separated by constant applied force
To determine the spring rate for a length not shown, divide the original length by the desired length, then multiply by the original spring rate.Example: The rate for No. 89581, cut to 1", would be 3 divided by 1, then multiplied by 2.0, or 6 lbs. per inch.
Technical Specifications
| Item#: | 89622 |
|---|---|
| Type | Compression Spring |
| O.D. | 3/8 " |
| Length | 1-1/2 " |
| I.D. | 5/16 " |
| Wire Diameter | 0.0258 " |
| Wire Gauge | 23 |
| Number of Coils | 14 |
| Rate | 1.3 lb./in. |
| Maximum Work Load | 2 lb |
| Material | Steel |
| UNSPSC #: | 31161904 |
| TAA Compliant: | Yes |
| Weight: | 0.06 lb |
